24 Brick
Product Code YT-03

24 Brick
24 Brick is classified at horizanal holed bricks.Is used at both Internal and external walls. Dimensions and weight may vary within tolerances. Thermal conductivity value is taken from TS 825 Appendix-E table. The Clay Products are classified as Class A1 without testing,according to the Regulations of the Fire.
Weight 5 kg
weight, may vary within tolerance
m² Unit 30 - 16
Need of m2 use may vary depending on the the dimensions,tolerances and thickness of the mortar used.The need of use per m2 is 28 unıts when the thickness of the wall is 240 mm and 16 units when 135mm.
Fire Response A1
The Clay Products are classified as Class A1 without testing,according to the Regulations of the Fire.
Resistance to freezing F0
Mamülün tasarlanan kullanım yerinde , su işlemesine karşı tam korunmuş olması ( uygun kalın sıva tabakası , kaplama yapılması veya sandviç duvarın iç kanadında veya bina içi duvarlarda kullanılması gibi ) halinde , donma çözünmeye karşı dirençli Olma şartı aranmaz.
Volume Weight 650 kg/m3
May vary depending on the D1 tolerance related to standard of TS EN 771-1.
Thermal Conductivity Account Value 0,320 W/mK
Loss of Sound Crossing (Rw) 43 dB
Pressure Resistance 2 N/mm2
Is used in partition walls;Carrier feature is missing.
Size 240 x 240 x 135
Horizontal Holed Bricks
Wall Thickness 240 - 135
Moisture Movement NPD
Bond Strength Sabit Değer 0,15 N/mm2
Water Absorption Açık hava koşullarına maruz bırakılmayan tip
Water Vapor 9,6 m
